1. ECE R10 EU E-Mark Certified
Passes ECE R10 electromagnetic compatibility standard — road-legal for use in EU member states and major export markets.

2. 100kg Lift Capacity
Rated to lift up to 100kg, comfortably handling most folding and power wheelchairs along with the user's belongings.

3. 858mm Maximum Lift Height
Raises the wheelchair up to 858mm from ground level (up to 910mm lift travel range), sufficient to clear the boot sill of SUV and MPV vehicles.

4. 0–100° Rotation Swing
The arm rotates 0–100°, positioning the wheelchair directly over the boot floor before lowering — no manual repositioning needed.

5. Triple Control Methods — Hand Switch, APP & Bluetooth
Operates via a physical hand-held switch, a smartphone APP, or Bluetooth wireless connection, providing flexible control for users with varying dexterity or caregiver preferences.

6. Dead-Man Control for Safety
The hoist moves only while the button is held; releasing it immediately stops motion at any position — preventing accidental drops during operation.

7. Quick-Detach Design — Space Saving When Not in Use
The entire unit can be rapidly removed from the vehicle when not needed, restoring full boot capacity for everyday use.

8. Easy Installation
Designed for straightforward fitting into the boot of SUV and MPV vehicles without permanent vehicle modification.

9. Left & Right Rotation Options
Available as WH3AR (right swing) or WH3AL (left swing) to suit different vehicle boot configurations and user loading preferences.

10. Compact & Lightweight Unit
At 22kg product weight, the hoist adds minimal mass to the vehicle while delivering a robust 100kg working load rating.

Technical Specifications

1 General Parameters

2 Model Dimension Table (Unit: mm)
